Remington 788 bolt handle

[hpshooter]

A friend called today and asked if I knew how the bolt handle was attached on a 788, he said his "broke off". Did a search here and found out that they do sometimes come loose but no information regarding how they are attached. I have not seen the rifle in question so I don't know if it actually broke or simply came loose from the bolt sleeve.. Can anyone tell me how they were originally attached?

Thanks in advance.



[Fast14riot]

Most of them are surface silver soldered. Ive seen people drill the bolt body about .180" deep for a pocket then weld the handle on.



[HillbillyLongRifle]

Send it to Dan Armstrong and have it Tig welded back on!



[drover]

Send it to Dan Armstrong and have it Tig welded back on!

Good advice - he will fix it properly, and inexpensively. http://accu-tig.com/

drover



[Dusty Stevens]

Good advice - he will fix it properly, and inexpensively. http://accu-tig.com/

drover

Whos taking the bets at whether or not dan will do a 788 bolt?



[GenePoole]

I bet not. That thing looks VERY different from a 700.



[Ggmac]

New bolt handles were available at Numrich. Only the ball and shank are part of the handle , not the surrounding piece ( collar ) you see on the bolt body .



[clowdis]

I also seem to remember the 788 bolt handle having a bad tendency to take a piece of the bolt sleeve with it when it breaks off. Check both. If the bolt sleeve is missing a chunk it's trash.



[Riesel]

Whos taking the bets at whether or not dan will do a 788 bolt?

I'm with Dusty on this one



[HillbillyLongRifle]

Dan tig welded my 788 handle back on a few years back!



[HillbillyLongRifle]

Whos taking the bets at whether or not dan will do a 788 bolt?

He fixed my 22-250 Rem 788 that I knocked the handle off of a few years back



[mac86951]

Ok, I'm betting the answer is, "sure, send it to me." Did i win? What are the stakes, 8lbs of H4350? Or is that too rich? Let's see, how about (10) 55gr FMJ .224? oOoOO, just looked that up too. Hmmm.... How about a picture of a box of small pistol primers?

-Mac



[hpshooter]

Thanks for the replies. Hope to see the bolt this week and assess what actual is "broken" and suggest a solution to the owner.



[Dusty Stevens]

He fixed my 22-250 Rem 788 that I knocked the handle off of a few years back

Thats real good. At least you know its fixed better than it came from remington!



[HillbillyLongRifle]

Thats real good. At least you know its fixed better than it came from remington!

Yes its the best 788 bolt handle attachment one can have!



[Tommie]

I’m the luckiest bastard here. Owned many 788’s and used to be a hotrodder when it came to load development. On several occasions I had to wack the bolt open with a piece of 2X4 board due to loads that were well beyond any published maximum. Never lost a bolt handle (or an eye). I’m not in any way doubting the bolt handle thing. Just grateful for dumb luck.
